| Main Processor | Embedded processor |
| Operating System | Embedded LINUX |
| Standard | NTSC(525Line,60f/s),PAL(625Line,50f/s) |
| Video Input | 4ch BNC / 1 ch IP Cable | 8ch BNC / 1 ch IP Cable | 16ch , / 1 ch IP Cable |
| Video Output | 1 HDMI,1VGA,1BNC |
| Audio Input | 1 channel or 2 channel |
| Audio Output | 1 channel or 2 channel |
| Display &Redording | |
| Resolution | 1920*1080,1280*1024,1280*720,1024*768,800*600 |
| Display Split | 1/4/8/9 1280*1024,20 |
| Privacy Masking | 4 rectangular zones(each camera) |
| OSD | Camera title,Time,Video loss,Camera lock,Motion detection,Recording |
| Video &Audio Compression | H.264/G.711 |
| Recording Resolution | 1080P (1920*1080/1280*600)/960h(960*576/960*480)/D1/4CIF(704*576/704*480)/ CIF(352*288/352*240)/QCIF(176*144/176*120) |
| Record Rate | Main stream :1080P /960P/720P/960H/D1/HD1/2CIF/CIF(1-25/30fps) |
| Extra Stream :CIF/QCIF(1-25/30fps) |
| Bit Rate | 48-6144kb/s |
| Record Mode | Manual,Schedule(Regular(continuous),MD),Stop |
| Record Interval | 1-120min(default;60min),Pre-record;1-30sec,Post-record:10-300 |
| Fuctions | |
| Trigger Events | Recording,PTZ,Tour,Video Push,Email,FTP,Spot,Buzzer&Screen |
| Video Detection | Video Detection,Motion Detection,MD Zones:396(22/8),Video loss&camera Blank |
| Alarm Input | 4 /8/16 channel |
| Sync Playback | 1/ 4 /8 optional |
| Search Mode | Time/Date,MD&Exact search(accurate to second) |
| Playback fuctions | Play,Pause,Stop,Rewind,Fast play,Slow play,Next file,Previous file,Next camera,Previous camera,Full screen,Repeat,Shuffle,Backup selection |
| Backup Mode | USB Device/network |
| Network&storage | |
| Network Ethernet | RJ-45 port(10/100M/1000M) |
| Network Functions | PPPOE,DDNS,FTP,IP Fiter |
| Smart Phone | iphone,ipad,Android,Windows,Phone |
| HDD | 1 OR 2 SATA port, up to 64TB |
